SKU:D0203010A001
Combined Relay with Overload Protector 1/10~1/2HP L-Sharp Black
Notice: The page shows FOB price.
GLOSOK Offers
OEM Services
Bulk Discounts
Couldn't load pickup availability
- 100,000+ Product Models
- Best Quality Assurance
- 24/7 Customer Service
- Local Logistics Delivery
![Combined Relay with Overload Protector 1/10~1/2HP L-Sharp Black](http://glosok.com/cdn/shop/files/D0203010A001-5.jpg?v=1728529359&width=1445)
![Combined Relay with Overload Protector 1/10~1/2HP L-Sharp Black](http://glosok.com/cdn/shop/files/D0203010A001.png?v=1728529376&width=1445)
![Combined Relay with Overload Protector 1/10~1/2HP L-Sharp Black](http://glosok.com/cdn/shop/files/D0203010A001-4.jpg?v=1728529388&width=1445)
![Combined Relay with Overload Protector 1/10~1/2HP L-Sharp Black](http://glosok.com/cdn/shop/files/D0203010A001-3.jpg?v=1728529398&width=1445)
![Combined Relay with Overload Protector 1/10~1/2HP L-Sharp Black](http://glosok.com/cdn/shop/files/D0203010A001-2.jpg?v=1728529407&width=1445)
![Combined Relay with Overload Protector 1/10~1/2HP L-Sharp Black](http://glosok.com/cdn/shop/files/D0203010A001-1.jpg?v=1728529416&width=1445)
Electrical parameters: AC230V 1-50A/110V 1-30A
Temperature operating range: 30-180 degrees centigrade
Insulation value:>100MΩ
Size: 35*40*85mm Weight: 50g
Horse Power: 1/10HP Matching power: 74W Suction current: 2.5A Release current: 2.0A
Horse Power: 1/8HP Matching power: 93W Suction current: 3A Release current: 2.6A
Horse Power: 1/6HP Matching power: 125W Suction current: 3.6A Release current: 3.0A
Horse Power: 1/5HP Matching power: 150W Suction current: 4.75A Release current: 3.75A
Horse Power: 1/4HP Matching power: 180W Suction current: 5.35A Release current: 4.25A
Horse Power: 1/3HP Matching power: 245W Suction current: 6.0A Release current: 4.75A
Horse Power: 1/2HP Matching power: 370W Suction current: 7.5A Release current: 6.0A
